VPC12-WPO-16

Slot-in PC for the ViewBoard® Interactive Displays and Presentation Display

Intel Core i5-8259U
High Definition Audio Stereo
Intel HD graphic 655
Max Resolution up to 4096x2304@60Hz
Windows 10 pro

Sales Enquiry

GALLERY

OVERVIEW

The ViewSonic® VPC12-WPO-16 slot-in PC is the ideal integrated solution for the ViewBoard® interactive displays and presentation displays. With dual-band Wi-Fi and Bluetooth, a powerful Intel® Core™ i5-8259U Processor, 8GB (up to 64GB) DDR4 SO-DIMM memory, and 256GB SSD storage, the VPC12-WPO-16 contains the computing power needed to operate CPU intensive applications.

SPECIFICATIONS

Core
CPU: Intel® Core™ i5-8259U
Grafik: Intel® Iris® Plus Graphics 655 Total Available Graphics Memory: 32GB Max Resolution up to 4096x2304@60Hz
Penyimpanan
Tipe: DDR4 SO-DIMM
Kapasitas: 8GB( up to 64GB )
Kapasitas: 256GB SSD
Interface: M.2 SATA Rev. 3
Perangkat lunak
Sistem operasi: Window10® Pro

INPUT
MIC (Mikrofon): x1
OUTPUT
HDMI: 1(max. resolution 4096x2160@30Hz)
Nirkabel / Bluetooth
Intel® Dual Band Wireless-AC 3165 802.11 ac/a/b/g/n (2.4GHz/5GHz) / BT4.2 ; BLE
USB
Tipe A: USB3.0 x 4
Tipe C: USB2.0 x 1
Mendukung Format Media
Format video: Container: ASF, WMA, WMV, WM, ASX, WAX, WVX , WMX, WPL, WMD, AVI, MPG, MPEG, M1V, MP2, MP3, MPA, MPE, M3U
Format gambar: Container: JPG, JPEG, JPE, JFIF, BMP, , DIB, PNG, GIF, TIF, TIFF
Audio codec: Container: MID, MIDI, RMI, AIF, AIFC, AIFF, WAV, CDA
Power
Tegangan: DC 12/19V
Konsumsi: 65W
OPERATING CONDITIONS
Suhu (º C): 23°F to 113°F (-5°C to 45°C)
Kelembaban: 10% ~ 90% non-condensing
DIMENSI (W x H x D)
Fisik (inci / mm): 202 x 119 x 30 mm / 7.95” x 4.69” x 1.18”
Kemasan (inci / mm): 254 x 196 x 77 mm / 10.00” x 7.72” x 3.03”
WEIGHT
Net (lb / kg): 0.8kg / 1.76lb
Gross (lb / kg): 1.1kg / 2.43lb
REGULATIONS
CE EMC, CE LVD, CE RED, RoHS, WEEE, BIS, WPC
