Featuring smooth motorized lift, the ViewSonic® VB-STND-004 motorized floor mount securely accommodates ViewSonic 55”, 65”, 75”, and 86" ViewBoard® interactive flat panel displays, or any display weighing up to 100 kg. With integrated on-screen control, the floor mount can be manipulated directly from the ViewBoard touchscreen (IFP50 series only), allowing you to easily raise or lower the ViewBoard with a single tap. A sturdy design ensures that the stand stays upright when secured and bolted to the floor.
Height Information
SPECIFICATIONS
Ergonomis
Penyesuaian Tinggi: 560mm (22.05”)
Braket pemasangan di dinding
up to 800x600mm
Bahan
Alumimum Alloy, Plastic, Steel
Memuat
Wall mount: 100 kg max. / 220.46 lb max. Plate: 20 kg max. / 44.09 lb max
Ukuran
Fisik (WxHxD): 960x1182x377 mm / 37.80x46.54x14.84 in Kemasan (WxHxD): 1155x305x795 mm / 45.47x12.01x31.30 in
Berat
Net: 44.3kg / 97.66lb Kotor: 53.5kg / 117.95lb
Input voltage
AC-in 100~240V 50/62Hz
Control panel
Control Pad, Physical button control , Software control for IFP50_IFP50-2
Penyesuaian
FCC, cTUVus, CE, CB, RCM
Item kotak masuk
Control Pad, Power Cord, Power Adapter Cord, USB Cable, Accessory Bag, Quick Start Guide
