VA916

W x H x D mm: 412 x 435 x 194 (with stand)

412 x 355 x 64 (without stand)

470 x 510 x 140 (packaging)

TCO’03, GS, ERGO, ISO 13406-2 (pixel failure class II), CE, CB, GOST-R, Hygienic (20 copies), UL, cUL, FCC-B (ICES), ICES-003B, NOM, SASO, ENERGY, ENERGY STAR, C-Tick, KTL/MIC, BSMI, PSB, MPR II, TUV-S/IRAM/UL-AR S Mark, CCC, VCCI, WEEE, RoHS

LCD Monitor, power cable, 15-pin VGA video cable, Quick Start Guide, CONTENT ViewSonic Wizard CD-ROM (User Guide/drivers) (multi-language)

Аналоговый: 15-pin mini D-Sub (detachable cable)
Питание: 3-pin AC plug (CEE22)

Напряжение : AC 100–240V, 50/60Hz (auto switch), internal power supply
Потребление: 32 watt (typ.), <1 watt in power save mode
TCO’03 and ENERGY STAR standards

Основные: Power, menu [1], up, down, select [2]
OSD: Auto image adjust, contrast, brightness, ViewMatch® colour adjust (sRGB, 9300K, 6500K, 5400K, user RGB), information (resolution, H/V frequency, pixel clock, model number, serial number), manual image adjust (H/V position, H size, fine tune, sharpness), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background), auto white balance, OSD/power lock, memory recall

Температура: 0°C–40°C
Влажность: 10%–90% (non-condensation)

Нетто: 3.8kg (with stand), 3.3kg (without stand)
Гросс: 5.0kg

Частота: Fh: 30–82kHz,
Fv: 50–75 Hz
Синх.: H/V separate (TTL)
Аналоговый: RGB analogue (0.7/1.0 Vp-p, 75 ohm)

Наклон: Down 5°, Up 20°

Kensington security port

VESA FDMI 100mm x 100mm
