PS502W

4,000 ANSI Lumens WXGA Short Throw Business & Education Projector​

  • 4,000 ANSI Lumens offering clear images in any environment​
  • 0.52 Short throw ratio for minimal space consumption​
  • Up to 300" ultra large screen with lower cost-per-inch​​
  • Easy and flexible connection: dual HDMI ports, USB Type-A port​
  • Convenient software updates for projectors via USB connection
Contactează-ne  Distribuie

PREZENTARE GENERALĂ

The PS502W is ViewSonic’s high brightness WXGA short throw business/education projector. Boasting 4,000 ANSI Lumens of high brightness, the projector offers clear images of up-to-300” large screen in meeting rooms, classrooms, or any other bright environment. With 0.52 short throw ratio, the projector can provide 100” large screen size from only 1.1 m away without being obstructed by shadows, allowing for a large screen even in small spaces. The dual HDMI ports allow you to flexibly connect to multiple devices, easily switching between content sources. The USB Type-A port can supply power to HDMI wireless dongles, making wireless content streaming more convenient. The projector also allows software updates via USB cable connection with simply your laptops, skipping trips to service centers. ​

High Brightness for Business & Education Environments​

Thanks to 4,000 ANSI Lumens brightness, you're guaranteed clear visuals of vibrancy, which are perfectly suitable for spaces with a lot of ambient light.
4,000 ANSI Lumens
High Brightness for Business & Education Environments​ 1

Big Screen for Small Spaces

The PS502W’s 0.52 short throw projection gives you 100” from only 1.3m away when positioning the projector. Presenters will stay clear of the projector beam, eliminating eye glare and shadows on the projection screen.
0.52 Short Throw
Big Screen for Small Spaces 1

Ultra-Large Screen with Lower Cost-per-inch​​

The projector allows for an up-to-300” image size, which is much larger and easier to install than commercial displays.
Up to 300"
Ultra-Large Screen with Lower Cost-per-inch​​ 1

Easy and Flexible Connection​

The dual HDMI ports offer ample connectivity to accommodate all your HDMI-enabled multimedia devices. You no longer have to unplug your existing device to switch to a new one. Simply use the on-screen display to select and change the input source.​
Dual HDMI Ports
Easy and Flexible Connection​ 1

Vibrant Colors for Captivating Presentations

Impress any audience with ViewSonic’s exclusive color technology and elevate your presentation with a true-to-life color experience.
Vibrant Colors for Captivating Presentations 1

A Simpler Way to Update Projector Software​

Skip trips to the service center by keeping software up to date easily and onsite via USB cable connection with your laptop.​​​
Learn more: https://youtu.be/irlhJLpDHas
​​​*The latest projector software update can be found in the download section at the bottom of the page when available.​
A Simpler Way to Update Projector Software​ 1

USB Type A Power Supply​

A built-in 5V/1.5A USB power output can be used to supply power to HDMI wireless dongles, eliminating the need for separate power adapters when streaming your multimedia content.
USB Type A Power Supply​ 1

Audio Right Out of the Box

The projector comes equipped with a 16W speaker, allowing for audio to be delivered during presentations without the need for external speakers.
Built-in 16W Speakers
Audio Right Out of the Box 1

Dimensions & I/O Ports

  1. Adjustment Foot
  2. Lens
  3. Front IR
  4. HDMI 1
  5. HDMI 2
  6. USB-A(5V/1.5A, Service)
  7. Computer In
  8. Audio In
  9. AC In
  10. R232
  11. Kensingtion Lock
  12. Monitor Out
  13. Audio Out
  14. Focus Ring
  15. LED Indicator
  16. Keypad

SPECIFICAȚII


  • Specificație
    Sistem de proiecție: 0.65" WXGA
    Rezoluție Nativă: 1280x800
    Luminozitate: 4000 (ANSI Lumens)
    Rată de contrast cu modul SuperEco: 15000:1
    Display Color: 1.07 Billion Colors
    Tip sursă de lumină: 240W UHP Lamp
    Light Source Life (hours) with Normal Mode: 4000
    Light Source Life (hours) with SuperEco Mode: 12000
    Lentile: F=2.8, f=7.51mm
    Decalaj de proiecție: 124.8%+/-10%
    Raportul de proiectare: 0.52
    Zoom optic: Fixed
    Zoom Digital: 0.8x-2.0x
    Dimensiune Imagine: 60"-300"
    Distanță de proiectare: 0.67m-3.36m
    (87"@0.97m)
    Intrare Keystone: +19°/-19° (V)
    Zgomot perceptibil (funcție Normal): 34dB
    Zgomot perceptibil (funcție Eco): 25dB
    Input Lag: 33.2ms
    Suport rezoluție: VGA(640 x 480) to FullHD(1920 x 1080)
    Compatibilitate HDTV: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
    Frecvență orizontală: 15K-102KHz
    Rată verticală de scanare: 23-120Hz
  • Input
    Intrare computer (partajare componentă): 1
    HDMI: 2
    (HDMI 1.4/ HDCP 1.4)
    Intrare audio (3.5mm): 1
  • Ieșire
    Ieșire monitor: 1
    Audio-out (3.5mm): 1
    Difuzor: 16W
    USB Tip A (Alimentare): 1 (5V/1.5A)
