VA1911a-LED

LED Backlight Monitor in a Small Format

LCD
Typ: 19" (18.5" viewable) Wide Color TFT Active Matrix LCD
Współczynnik kontrastu: 700:1 (typ.)
Kąty widzenia: 90º horizontal, 65º vertical
Display Area: 16.1" horizontal x 9.1" vertical; 18.5" diagonal
Optimum Resolution: 1366x768
Czas reakcji: 5ms (typ)
Panel Surface: Anti-glare, hard-coating (3H)
Jasność: 200 cd/m² (typ.)
Dynamiczny kontrast: Ratio 10,000,000:1
Backlight: White-light LED
Czas pracy podświetlenia: 30,000 hours (min.)
COMPATIBILITY
PC: PC compatibles (VGA up to 1366x768 non-interlaced)
Mac®: Up to 1366x768
DIMENSIONS
Physical With Stand: 17.5 x 14.1 x 7.1 in. / 444.3 x 358.7 x 180 mm
Physical Without Stand: 17.5 x 10.8 x 2.1 in. / 444.3 x 276.5 x 53.6 mm
Packaging: 19.5 x 15.9 x 5.0 in. / 495 x 405 x 128 mm

WARRANTY
Three-year limited warranty on parts, labor and backlight
RECYCLE/DISPOSAL
Please dispose of in accordance with local, state or federal laws.
CONNECTOR
Moc: Internal Power Board, 3-pin plub (CEE22)
Analog: 15-pin mini D-sub (VGA)
POWER
Napięcie: AC 100–240V (universal), 50 / 60Hz
Zużycie energii: 15W (typ.) / 17W (max.)
Optimize: 9.9W (typ.)
Conserve: 9W (typ.)
CONTROLS
Front Panel: Power, 1, up, down, 2
OSD: Auto Image Adjust, Contrast/Brightness, Color Adjust (sRGB, Bluish, Cool, Native, Warm, User Color [R,G,B]), Information, Manual Image Adjust (H/V Position, Horizontal Size, Fine Tune, Sharpness, Dynamic Contrast, Aspect Ratio, Eco-mode), Setup Menu (Language Select, Resolution Notice, OSD Position, OSD Timeout, OSD Background, Auto Power Off, Power Indicator), Memory Recall
OPERATING CONDITIONS
Temperatura: 32–104º F (0–40º C)
Wilgotność powietrza: 10–90% (non-condensing)
VESA® MOUNT
100x100 mm
VIDEO INPUT
Frequency: Fh: 24~82kHz, Fv: 50~75Hz
Sync: Separate Sync
Analog: RGB analog (0.7 / 1.0 Vp-p, 75 ohms)
POWER MANAGEMENT
ENERGY STAR® standards
ERGONOMICS
Nachylenie: Forward 5º, Back 21.5º
WEIGHT
Brutto: 7.8 lb. / 3.6 kg
Net With Stand: 6.3 lb. / 2.8 kg
Net Without Stand: 5.9 lb. / 2.7 kg
Zawartość opakowania
VA1911a-LED display, power cable, video cable, Quick Start Guide, ViewSonic Wizard CD (available in some countries only), Base instruction guide
