PJ258D

Dual Performance Multimedia Projector with Keystone correction

Display
Type: 0.55" Digital Micromirror Device (DLP™)
Resolution: 1024x768, 1280x1024, (compressed)
Lens: Manual zoom/focus (1:1.2x)
Size: 30 - 300 inch
Throw Distance: 1.2m - 11.6m
Lamp: 200 watt AC HID
Brightness: 2000 ANSI Lumens
Contrast Ratio: 2000:1
Keystone Correction: Vertical Digital ±15°
Aspect Ratio: 4:3 & 16:9
Audio
Speakers: 2 w @ 4 ohms x 1 mono
Input Signal
Video: RGB analog, NTSC, PAL, SECAM, HDTV (480i/p, 576i/p, 720p, 1080i)
Sync: H/V separated
Frequency: Fh: 31-79KHz; Fv: 56-85Hz

Compatibility
PC: VGA to XGA
Mac: Up to SXGA (may require Mac Adapter)
Connector
RGB Input: 15-pin HD D-sub cable (x1)
Composite Video: RCA jack (x1)
S Video: Mini-DIN 4 pin (x1)
Component Video: DSub-15 to Component Video Adapter (Option)
Audio: Input: 3.5mm stereo mini-jack (x1)
Control: RS-232 (9 Pin D-sub) x 1
USB: x1 (Service Only)
Power
Voltage: 100-240VAC (Auto Switching); 50/60Hz (universal)
Consumption: 280W (typ)
Controls
Basic: Standby/On, input, menu
OSD: All Image: Contrasts, Brightness, Keystone, Aspect Ratio, Blank Screen, Gamma, White Peaking, Color Temperature, Red, Green, Blue
Video: Saturation, Tint, Sharpness
Display: Phase. Tracking, H. Position, V. Position
Advance: Auto Source Select, Rear, Ceiling, ECO Mode, Lamp Hours, Color Space, Auto Shutdown, OSD Timeout, Menu Position, Factory Reset
Operating Conditions
Temperature: 0°C - 40°C (32°F - 104°F)
Humidity: 10% - 90% (non-condensing)
Dimensions
Physical: 288mm (width) x 83mm (height) x 190mm (depth)
Weight
Net: 1.8 kg
