XG2702

27" 144Hz Gaming Monitor

AMD FreeSync™ technology
1ms response time
Black stabilization
ColourX preset mode
ViewScale technology

GALLERY

SPECIFICATIONS

Display
Display Size (in.): 27
Viewable Area (in.): 27
Panel Type: TN Technology
Resolution: 1920 x 1080
Resolution Type: FHD (Full HD)
Static Contrast Ratio: 1,000:1 (typ)
Dynamic Contrast Ratio: 120M:1
Light Source: LED
Brightness: 400 cd/m² (typ)
Colors: 16.7M
Color Space Support: 8 bit (6 bit + FRC)
Aspect Ratio: 16:9
Response Time (Typical GTG): 1ms
Viewing Angles: 170º horizontal, 160º vertical
Backlight Life (Hours): 30000 Hrs (Min)
Curvature: Flat
Refresh Rate (Hz): 144
Variable Refresh Rate Technology: FreeSync Premium
Low Blue Light: Software solution
Flicker-Free: Yes
Color Gamut: NTSC: 72% size (Typ)
sRGB: 103% size (Typ)
Pixel Size: 0.311 mm (H) x 0.311 mm (V)
Surface Treatment: Anti-Glare, Hard Coating (3H)
Compatibility
PC Resolution (max): 1920x1080
Mac® Resolution (max): 1920x1080
PC Operating System: Windows 10 certified; macOS tested
Mac® Resolution (min): 1920x1080
Connector
USB 3.2 Type A Down Stream: 4
USB 3.2 Type B Up Stream: 1
3.5mm Audio Out: 1
HDMI 2.0: 1
HDMI 1.4: 1
DisplayPort: 1
Power in: 3-pin Socket (IEC C14 / CEE22)

Audio
Internal Speakers: 3Watts x2
Power
Eco Mode (Conserve): 26W
Eco Mode (optimized): 30W
Consumption (typical): 37W
Consumption (max): 40W
Voltage: AC 100-240V
Stand-by: 0.5W
Power Supply: Internal Power Supply
Additional Hardware
Kensington Lock Slot: 1
Cable Organization: Yes
Controls
Physical Controls: G, Up, Down, A, B, Power
On Screen Display: Gaming Settings, Display, Input Selet, ViewMode, Audio Adjust, Setup Menu
Operating Conditions
Temperature: 32°F to 104°F (0°C to 40°C)
Humidity (non-condensing): 20% to 90%
Wall Mount
VESA Compatible: 100 x 100 mm
Input Signal
Frequency Horizontal: HDMI (v1.4): 15 ~ 180KHz, HDMI (v2.0): 15 ~ 180KHz, DisplayPort (v1.2): 15 ~ 180KHz
Frequency Vertical: HDMI (v1.4): 24 ~ 144Hz, HDMI (v2.0): 24 ~ 144Hz, DisplayPort (v1.2): 48 ~ 144Hz
Video Input
Digital Sync: TMDS - HDMI (v1.4), TMDS - HDMI (v2.0), PCI-E - DisplayPort (v1.2)
Ergonomics
Height Adjust (mm): 120
Swivel: 90º
Tilt (Forward/Back): -5º / 15º
Pivot (Right/Left): 90º / 0º
Weight (imperial)
Net (lbs): 19.7
Net Without Stand (lbs): 12.6
Gross (lbs): 24.7
Weight (metric)
Net (kg): 9
Net Without Stand (kg): 5.7
Gross (kg): 11.2
Dimensions (imperial) (wxhxd)
Packaging (in.): 29.7 x 18.5 x 8.5
Physical (in.): 25.3 x 17.17~21.9 x 9.4
Physical Without Stand (in.): 25.3 x 15.4 x 2.6
Dimensions (metric) (wxhxd)
Packaging (mm): 755 x 469 x 215
Physical (mm): 642 x 436.2~556.2 x 239
Physical Without Stand (mm): 642 x 391 x 65
General
PACKAGE CONTENTS: XG2702 x1, 3-pin Plug (IEC C13 / CEE22) x1, DisplayPort Cable (v1.2; Male-Male) x1, USB A/B Cable (v3.2; Male-Male) x1, Quick Start Guide x1
Recycle/Disposal: Please dispose of in accordance with local, state or federal laws.
Warranty: *Warranty offered may differ from market to market
