ViewSonic LCD Display VG2401mh

VG2401mh

24” 144Hz Fully Ergonomic Gaming Display

GALLERY

SPECIFICATIONS

LCD
Type: 24" diagonal color active matrix TFT LCD
Display Area: 24 inch
Optimum Resolution: 1920x1080
Contrast Ratio: 1000 :1 (typical), 30,000,000:1 (DCR)
Brightness: 350 cd/m² (typ)
Viewing Angles: 170° / 160°
Response Time: 1ms?Gdelta?
Panel Surface: Anti-Glare type, Hard-coating (3H)
Light Source: 30000 Hrs (Min)
Colors: 16.7 M (true 8-bit)
Video Input
Digital: HDMI / DVI/DP (TMDS, 100ohms)
Frequency: Fh: 24-160KHz; Fv: 50-145Hz
Sync: Separate Sync/ Composite Sync/ Sync on Green
Compatibility
PC: PC Compatibles (up to 1920x1080 Non Interlaced)
Mac: Mac (up to 1920x1080 )

Ergonomics
Tilt: 20° ~ - 5°
Pivot: 90°
Height Adjust: 0-120mm
Connector
Digital: DVI-D x1, DisplayPort x1, HDMI x2
USB: USB 3.0 x2
Audio: Earphone out x1(3.5mm plug); Audio in x1(3.5mm plug)
Power: Internal power board
Audio
Speakers: 3W x2
Power
Voltage: AC 100-240V (Universal); 50/60 Hz
Consumption: 37W(Typ); Optimize:32W(Typ); Conserve:27W(Typ)
Operating Conditions
Temperature: 32°F to 104°F (0°C to 40°C)
Humidity: 10% to 90% (no condensation)
Dimensions
Physical: 568.2mm (width) x 529.7mm (height) x 217.9mm (depth)
Weight
Net: 6.5 kg
Wall Mount
VESA® 100x100 mm
