Archived

VG2233Smh

22" Ergonomic Business Monitor

LCD
유형: 21.5" Wide Color a-Si TFT Active Matrix 1920x1080 LCD
Display Area: 21.5 inch
Optimum Resolution: 1920x1080
대비 비율: 1000:1 (typical), 20,000,000:1 (DCR)
밝기: 250 cd/m² (typ)
보기 각도: 178° / 178° (typ)
응답 시간: 4ms（GTG）
Panel Surface: Anti-Glare, Hardness 3H
광원: 30,000 Hrs
Colors: 16.7M
비디오 입력
Analog: RGB Analog (75 ohms, 0.7 / 1.0 Vp-p)
Digital: HDMI (TMDS, 100ohms) / DVI (TMDS, 100 ohms)
Frequency: Fh: 24-82KHz; Fv: 50-75Hz
Sync: Separate Sync/ Composite Syn/ Sync on Green
호환성
PC: PC Compatibles (VGA up to 1920x1080 Non Interlaced)
Mac: Power Mac (up to 1920x1080)

인체공학
틸트: 25º ~ - 5º
회전: 340º
Pivot: 90º
높이 조정: 0-100mm
커넥터
Analog: VGA x1
Digital: DVI x1, HDMI x1
오디오: 3.5mm plug x1
힘: Internal Power Board , 3-pin plug (CEE22)x1
오디오
Speakers: 2-Watt x2
힘
전압: AC 100-240V (Universal); 50/60 Hz
소비.: 22 W (typ); Optimize:18 W (typ); Conserve:14 W (typ)
작동 조건
온도: 32°F ~ 104°F / 0°C ~ 40°C
습도: 10% to 90% (no condensation)
치수
Physical: 505.6mm (폭) x 361mm (신장) x 204.3mm (깊이)
체중
그물: 4.8 kg
규정
WEEE, RoHS,CE,CB Window7, Windows 8, Energy Star 6.0 for EPEAT Gold, C-Tick, MEPS, PSB, BSMI
벽 마운트
VESA® 100x100 mm
Package Contents
LCD Display, Power Cable, Video Cable, Quick Start Guide, ViewSonic Wizard CD-ROM
