VA2405-h
24”1080p Monitor with HDMI and VGA Input
- HDMI and VGA Input
- Eye-care technology for comfortable viewing
- Eco-mode for low energy consumption
- ViewMode color rendering options
- 75 Hz AMD FreeSync™ for smooth, continuous visuals
- VESA wall mountable
SPECIFICATIONS
- 표시디스플레이 크기(인치): 24
표시 가능한 영역(인치): 23.6
패널 유형: VA Technology
결의안: 1920 x 1080
해상도 유형: FHD (Full HD)
정적 대비 비율: 3,000:1 (typ)
동적 대비 비율: 50M:1
광원: LED
밝기: 250 cd/m² (typ)
Colors: 16.7M
Color Space Support: 8 bit (6 bit + Hi-FRC)
가로 세로 비율: 16:9
응답 시간(일반 GTG): 4ms
보기 각도: 178º horizontal, 178º vertical
백라이트 수명(시간): 30000 Hrs (Min)
곡률: Flat
새로 고침 빈도(Hz): 75
가변 리프레시 레이트 기술: FreeSync
블루라이트 필터: Yes
Low Blue Light: Software solution
깜박임 없음: Yes
Color Gamut: NTSC: 72% size (Typ)
sRGB: 104% size (Typ)
픽셀 크기: 0.272 mm (H) x 0.272 mm (V)
표면 처리: Anti-Glare, Hard Coating (3H) - 호환성PC 해상도(최대): 1920x1080
Mac® 해상도(최대): 1920x1080
PC 운영 체제: Windows 10/11 certified; macOS tested
Mac® 해상도(분): 1920x1080 - 커넥터VGA: 1
HDMI 1.4: 1
전원 투입: 3-pin Mickey Mouse Socket (IEC C6)
- 힘에코 모드(보존): 14W
Eco Mode (optimized): 17W
소비(일반): 20W
소비량(최대): 21W
전압: AC 100-240V
대기: 0.3W
전원 공급 장치: Internal Power Supply - 추가 하드웨어켄징턴 잠금 슬롯: 1
- 컨트롤물리적 제어: Key 1 (favorite), Key 2, Key 3, Key 4, Key 5 (power)
화면 디스플레이: Input Select, ViewMode, Color Adjust, Manual Image Adjust, Setup Menu - 작동 조건온도: 32°F to 104°F (0°C to 40°C)
습도(결로하지 말 것): 20% to 90% - Wall Mount VESA 호환: 100 x 100 mm
- 입력 신호주파수 수평: 24 ~ 86KHz
주파수 수직: 48 ~ 75Hz - 비디오 입력디지털 동기화: TMDS - HDMI (v1.4)
Analog Sync: Separate - RGB Analog - 인체공학틸트(전진/후진): -5º / 20º
- 무게(제국)네트(lbs): 7.1
스탠드 없는 네트(lbs): 6.2
총계(lbs): 9.9 - Weight (metric) 순(kg: 3.2
스탠드없는망(kg): 2.8
그로스(kg): 4.5 - 치수(제국)(wxhxd)포장(in.): 24 x 15.7 x 5.5
물리적(인치): 21.6 x 16 x 7
물리적(스탠드 없음): 21.6 x 12.8 x 1.6 - 치수(메트릭)(wxhxd)포장(mm): 610 x 400 x 140
물리적(mm): 548 x 406 x 177
물리적 스탠드 미포함 (mm): 548 x 324 x 41 - 일반규정: cTUVus, FCC-B, ICES003, CEC, IQC-ST, MX-CoC, Mexico Energy, REACH, WEEE, RCM, GEMS, BIS, CCC, China RoHS, China Energy Label, CECP
패키지 내용물: VA2405-H x1, 3-pin Mickey Mouse Plug (IEC C5) x1, HDMI Cable (v1.4; Male-Male) x1, Quick Start Guide x1
재활용/폐기: Please dispose of in accordance with local, state or federal laws.
보증: *Warranty offered may differ from market to market
