TD2455

24” In-Cell Touch Monitor with USB Type-C Input and Advanced Ergonomics

  • Versatile touch applications
  • Accurate yet smooth touch experience
  • USB Type-C one cable solution
  • DisplayPort out supporting Daisy Chain
  • Highly adjustable working angles to suit different needs

SPECIFICATIONS


  • Display
    Dimensione display (in.): 24
    Area visualizzabile (in.): 23.8
    Tipo pannello: IPS Technology
    Risoluzione: 1920 x 1080
    Tipo risoluzione: FHD
    Contrasto statico: 1,000:1 (typ)
    Contrasto dinamico: 50M:1
    Tecnologia: LED
    Luminosità: 250 cd/m² (typ)
    Colors: 16.7M
    Color Space Support: 8 bit (6 bit + A-FRC)
    Rapporto d'aspetto: 16:9
    Tempo di risposta (Tipica GTG): 6ms
    Tempo di risposta (GTG w/OD): 6ms
    Angolo visuale: 178º horizontal, 178º vertical
    Durata (ore): 30000 Hrs (Min)
    Curvatura: Flat
    Refresh Rate (Hz): Max. 75Hz (HDMI (v1.4), DisplayPort (v1.2), Type C) (Max)[1]
    Blue Light Filter: Yes
    Flicker-Free: Yes
    Color Gamut: NTSC: 72% size (Typ), sRGB: 102% size (Typ)
    Pixel Size: 0.275 mm (H) x 0.275 mm (V)
    Touch Screen: Projected Capacitive, 10-point multi-touch
    Trattamento della Superficie: Anti-Glare, Hard Coating (3H)
  • Compatibilità
    Risoluzione PC (max): 1920x1080
    Risoluzione Mac® (max): 1920x1080
    Sistema operativo: Windows 7/8.1/10/11 certified; macOS tested
    Risoluzione Mac® (min): 1920x1080
  • Connessioni
    USB 3.1 Tipo A: 1
    USB 3.1 Tipo B: 1
    USB 3.1 Tipo C: 1
    Uscita audio 3.5mm: 1
    HDMI 1.4: 1
    Display Port: 1
    Display Port Out: 1
    Alimentazione: 3-pin Socket (IEC C14 / CEE22)
  1. The Max. refresh rate may vary by I/O port, resolution, user environment and settings. For additional information please check the the “Specifications” section in the user guide.
