ViewBoard IN6501-G
ViewBoard® 65" 4K Interactive Display
- Powered by Android 14
- Embrace simplicity and organization with the USB-C one-cable solution
- Intuitive user interface and fast app launch for smooth operation
OVERVIEW
The ViewBoard IN6501-G is the interactive flat panel that delivers exceptional image quality in 4K UHD, thanks to cutting-edge bonding technology that provides clearer colors, enhanced contrast, and reduced glare. The 40-point touchscreen interface, equipped with Ultra Fine Touch Technology, empowers students and teachers to collaborate seamlessly, using either their fingers or dual-tip pens, for an intuitive pen-on-paper experience. Powerful built-in speakers and a USB-C port sort out for a complete and convenient user experience.Performance and Security with Android 14
Equipped with a high-performance octa-core CPU, the IN01-G Series delivers exceptional multitasking capabilities. Powered by the latest Android 14 OS, it ensures seamless operation across demanding applications while keeping you ahead with cutting-edge efficiency, advanced features, and robust security enhancements.Smooth Writing for Intuitive Collaboration
Designed for sharing ideas and student collaboration, the ViewBoard features 40 touchpoints with Ultra-Fine Touch technology and dual-pen capabilities. Experience an enhanced pen-on-paper writing experience as you alternate between the two pens’ dual-tips to effortlessly switch line color and thickness.Speakers Deliver Elevated Audio Quality
Captivate students with compelling lessons thanks to the built-in dual 20W speakers. Whether sharing instructional videos, musical content, or delivering listening exercises, the IN6501-G brings profound audio depth to create memorable experiences.
SPECIFICATIONS
- DisplayPanel Size: 65"
Panel Type: TFT LCD Module with DLED Backlight, ADS
Display Area (mm): 1428.48(H) × 803.52(V) (64.5” diagonal)
Aspect Ratio: 16:9
Resolution: UHD 3840x2160(Pixels)
Colors: 1.07B colors
Brightness: 450 nits
Contrast Ratio: 1200:1
Response Time: 8ms
Viewing Angles: H=178, V=178
Backlight Life: 50,000 Hours
Surface Treatment: Hardness: 9H Anti-glare coating
Orientation: Landscape - PlatformProcessor: Octa-core ARM Cortex (A55*8 )
RAM: 8GB DDR4
Storage: 128GB - TouchType/ Tech: Ultra Fine Touch Technology
Touch Point: Windows: 40 Android: 40
- INPUTHDMI: x3 (Frontx1:HDMI2.0 ; Rearx2 [(HDMI2.0 with CEC/ARC)x1, (HDMI2.0 with CEC)x1]
RGB / VGA: x1
Audio: x1
RS232: x1
OPS: x1 (Optional Intel Standard OPS)
WiFi: x1 (Built-in) - OUTPUTHDMI: x1
Audio: x1
SPDIF: x1 - LANRJ45: x1
- USBType A: USB3.0:Front x3, Rear x1；
USB2.0:Rear x1 (Support OTG)
Type B: USB 2.0:Frontx1, Rear x1
Type C: USB 2.0:Frontx1 - SPEAKERS20W x 2
- Embedded OSAndroid 14
- Special FeaturesAll-in-one USB port: (combine slot-in PC/Android/HDMI USB port) Front “SmartPort™ USB” to all channels.
- PowerVoltage: 100-240V AC
Consumption: On: 190W ; Off: <0.5W - ERGONOMICSWall Mount (VESA® ): 500*400
- OPERATING CONDITIONSTemperature (º C): 0°C to 40°C
Humidity: 20% ~ 80% RH non-condensing - DIMENSIONS (W x H x D)Physical (inch / mm): 58.80x35.37x3.69(in) / 1493.4x898.5x93.7(mm)
Packaging (inch / mm): 63.85x40.00x7.48(in) / 1622x1016x190(mm) - WEIGHTNet (lb / kg): 76.5lb/34.7kg
Gross (lb / kg): 90.9lb/41.7kg - REGULATIONSBIS
- PACKAGE CONTENTS1. 3m power India power plug x 1 2. 3m HDMI cable x 1 3. 5m Touch USB cable (USB2.0) x 1 4. Touch pen x 2 5. WiFi Dual band antenna x 2 6. Remote control x 1 7. AAA battery x 2 8. Quick Start Guide with Compliance statement 9. Screw x 4 (wall mount M8*25mm)
- Compatible Slot-in PCVPCF5-W55-G1 / VPC37-W53-G1 / VPC35-W53-G1
