VA2447-LED

Large screen boosts viewing experience with delights

LCD
Contrast Ratio: 1000:1
Viewing Angles: 170° / 160°
Display Area: 23.6" / 59.9cm Wide
Optimum Resolution: 1920 x 1080
Response Time: 5 ms
Panel Surface: Anti-Glare Type, 3H Hardness
Pixel Clock: 0.2715 mm x 0.2715 mm
Brightness: 250 cd / m²
Dynamic Contrast Ratio: 10,000,000:1
Backlight: White-light LED
Backlight Life: 30,000 Hrs (Min.)
COMPATIBILITY
PC: VGA up to 1920 x 1080 (Non-interlaced)
Mac®: Power MAC (up to 1920 x 1080)
DIMENSIONS
Physical With Stand: 574.64 x 431.2 x 234(mm)

22.62" x 17" x 9.21"(inch)
Physical Without Stand: 574.64 x 375.74 x 44.76(mm)

22.62" x 14.79" x 1.76"(inch)

INPUT
Sync: Separate Sync
Analogue: RGB Analog (75Ω, 0.7 / 1.0 Vp-p)
Frequency: Fh = 24 ~ 82 kHz ; Fv = 50 ~ 75 Hz
CONNECTOR
Digital: DVI-D*1
Analog: D-sub*1
Power: Internal Power Board, 3-pin Plug (CEE22) *1
POWER
Voltage: AC 100 - 240V (Universal); 50 / 60 Hz
Consumption: 29W
Eco Mode: Optimize: 19 W

Conserve: 15 W
VESA® MOUNT
100mm x 100mm
ERGONOMICS
Tilt: 20° ~ -5°
WEIGHT
Net With Stand: 10.14 lbs (4.6 Kg)
Net Without Stand: 9.26 lbs (4.2 Kg)
OPERATING CONDITIONS
Humidity: 10% to 90% (No condensation)
Temperature: 32° F to 104° F (0° C to 40° C)
