EP3202r

Impactful High-Definition Digital Poster

COLORS
Black
COMPATIBILITY
Card Reader: 2GB Compact Flash
Photo Formats: JPEG baseline 5120x3840, progressive 2048x1536
Audio Formats: LPCM, sampling rate: 32–48KHZ/16–24 bit, MPEG1 Layer 3, sampling rate: 32–48KHZ, bit rate: 32–320Kbps
DIMENSIONS
Physical (WxHxD): 19.2" x 31.5" x 3.4" (490mm x 800mm x 87mm)

PACKAGE CONTENTS
ePoster, power cord, remote control with batteries, key, wall mount
bracket, Quick Start Guide, User Manual and Software on CD
AUDIO
Speaker: 2W (x2)
CONNECTOR
USB: 1.1 (x1)
Ethernet: RJ45 (10/100M)
POWER
Consumption: Max 145W
Save Mode (W): Off < 1W
Supply: 3.2–1.38 A @ 100–240VAC, 50/60Hz
DISPLAY
Contrast Ratio : 5000:1 (typ)
Display size: 32" (81.3 cm)
Resolution: 1366x768 dots
Color Depth: Over 16.7M color (depending on video card used)
Response Time: 8ms (typ gray-to-gray)
Viewing Angles: Up and down 178º, left and right 178º (typ) @ CR>10
Brightness: 450 cd/m2 (typ)
VESA MOUNT COMPLIANT
400mm x 200mm, 350mm x 330mm
WEIGHT
Gross: 66.1 lbs. (30.0 kg)
Net: 62.8 lbs. (28.5 kg)
OPERATING CONDITIONS
Humidity: 20–90% (non-condensing)
Temperature: 32–122º F (0–50º C)
STORAGE ENVIRONMENT
Humidity: 10–90% (non-condensing)
Temperature: -4–158º F (-20–70º C)
CONTENT MANAGEMENT
Operating System: MS Windows
Software: ePoster Manager Express
MTBF
50,000 hrs.
