Archived
CDE9800
98" 4K Ultra HD Presenation Display
- ViewBoard® Cast 4-way split screen content sharing software
- USB Plug and Play
- Remote Management with vController™ Software
- Supports HDMI CEC Pass Through
- Embedded LAN, Optional Wi-Fi, Internet Browser
SPECIFICATIONS
- DisplayPanel Size: 98"
Type/ Tech: TFT LCD Module with LED Backlight
Display Area (mm): 2158.848mm*1214.352mm
Native Resolution: 3840 x 2160
Aspect Ratio: 16:9
Colours: 1.07B (10bit)
Brightness: 500 nits(typ.)
Contrast Ratio: 1300:1
Response Time: 5 ms(typ.)
Viewing Angles: H = 178, V = 178 (typ.)
Backlight Life: 30,000 hrs(min.)
Surface Treatment: 3H, Haze 1% (typ)
Bezel: 20.3mm
Orientation: Landscape - INPUTHDMI: x2
1 port to support CEC
RGB / VGA: 1
DisplayPort: DP1.2 x1
Audio: PC audio in (3.5 mm) x1
RS-232: x1
OPS: OPS x1
SDM-L x1 - OUTPUTHDMI: HDMI2.0 x1
Audio: 3.5mm Earphone Out x1
SPDIF: x1
- LANRJ45: X2
10M/100 - USBType A: USB2.0 x2
- SPEAKERSSPEAKERS: 16W x2
- COMPATIBILITYHDMI: HDMI in: 4k@60Hz
HDMI out: 1080/4k @60Hz
DisplayPort: 3840x2160@60Hz
Android Version: Resolution: 1080p - POWERVoltage: 100-240VAC +/- 10% Wide Range
Consumption: On: 385W(Typ.)
Off: <0.5W - ERGONOMICSWall Mount (VESA® ): 800x600mm
- OPERATING CONDITIONSTemperature (º C): 0°C to 40°C
Humidity: 20% ~ 80% RH non-condensing - DIMENSIONS (W x H x D)Physical (mm): 2198.8*109.5*1253.8mm
Packaging (mm): 2525*435*1750mm - WEIGHTNet (kg): 104.5 kg
Gross (kg): 153.65 kg - PACKAGE CONTENTSPACKAGE CONTENTS: 1. US/EU/UK/AU power cord 3M
2. QSG
3. Compliance statement
4. HDMI cable 3M*1
5. Remote control with AAA batteries
6. Webcam plate
7. Wall mount screws
