VX2336s-LED
23” LED Display with an Ultra-wide Viewing Angle
REVIEWS
“In general, we can say that emerged in 2012 ViewSonic VX2336s significantly changes standards in the class of budget monitors for home and office. Currently, this kind of device may well have a screen with a diagonal of 23 inches or more, and use high-quality IPS matrix with good color, brightness, contrast and color gamut. ”
SPECIFICATIONS
- COLORSBlack
- LCDRatio de contraste: 1,000:1
Ángulos de visión: 178o /178o (typ.)
Área de visualización: 23” Wide
Resolución óptima: 1920 x 1080
Tiempo de respuesta: GTGbw: 6 ms
Superficie del panel: Anti-Glare type, Hardness 3H
Tamaño del píxel: 0.265 x 0.265 mm
Brillo : 250 cd/m²
Relación de contraste dinámico: 20,000,000 : 1
Retroiluminación: WLED，30,000 Hrs (Min.) - COMPATIBILIDADPC: VGA up to 1920 x 1080 (Non Interlaced)
Mac®: Power MAC (up to 1920 x 1080)
- DimensionesFísicas con la base: 548 x 426 x 201 (mm) /
21.57” x 16.77” x 7.91” (in)
Físicas sin la base: 548 x 346 x 60 (mm) /
21.57” x 13.62” x 2.36” (in) - NormativasCE, CB, WEEE, RoHS, REACH SVHC List,Energy Star 5.0, Windows 7 / Vista Premium/ XP,UL, cUL, FCC/ ICES003, EPEAT Silver,
GOST-R+Hygienic, UkrSEPRO, ErP, CCC,CEL, BSMI,PSB, C-TICK - EntradaSyncronización: Separate Sync
Analógico: RGB Analogue (75 ohms, 0.7 / 1.0 Vp-p)
Frecuencia: Fh = 24 ~ 83 kHz ; Fv = 50 ~ 76 Hz - ConectividadAnalógico: 15-pin mini D-sub x 1
Digital: DVI-D x 1
Alimentación: Internal Power Board , 3-pin plug (CEE22) x 1 - AlimentaciónVoltaje: AC 100-240V (Universal); 50/60 Hz
Consumo: 35W (Max); 21W (ECO Mode) - OtroKensington Hole
- MONTAJE EN LA PARED100mm × 100mm
- ERGONOMÍA20~-5 degrees
- PesoNeto: 3.63 Kg (8.00 lbs)(with stand)
3.23 Kg (7.12 lbs)(without stand) - CONDICIONES DE FUNCIONAMIENTOHumedad: 20% to 90% (No Condensation)
Temperatura: 0 - 40 (°C)
