Screen Size: | 135'' |
Surface d'affichage (mm): | 3000 (H) x 1687.5(V) |
Résolution native: | 1920x1080 |
Panel Technology: | Direct view LED |
LED Package Type: | SMD 3 in 1 |
Pixel Pitch (mm): | 1.56 |
Refresh Rate: | 4440Hz |
Brightness (max.): | 600 nits (8 levels adjustable) |
Contrast Ratio (typ.): | 6000:1 |
Orientation: | Landscape |
Viewing Angles (typ.): | H = 160, V = 160 |
LED Lifetime (typ.): | 100,000 Hours |
Stockage local: | Total 64GB (56GB available storage) |
Système d'exploitation embarqué: | Android 9.0 |
Prise en charge de la résolution: | VGA(640 x 480) to 1080p(1920 x 1080) |
Compatibilité HDTV: | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160P/60Hz |
Fréquence horizontale: | 23-120 kHz |
Fréquence de balayage vertical: | 15-135 Hz |
HDMI: | x6 (HDMI 2.1 x 1, HDMI 2.0 x 3, HDMI 1.4 x 2) |
USB Type A: | x3 ( USB2.0 x3) |
RJ45 Input (Internet): | x1 |
IR in: | x1 |
Wi-Fi Input: | 2.4G/5G Hz |
USB Type C: | x1 (Video input、 Power output (5V/2A)) |
HDMI out: | x2 (HDMI 2.0 external x1,internal x1) |
Haut-parleur: | 20W x2 (Harman Kardon) |
Sortie audio (3,5 mm): | x1 |
USB Type A (Alimentation): | Shared with USB input (5V/1.5A x3) |
USB Type A (Services): | x1(shared with USB A input) |
RS232 (DB 9-pin female): | x1 |
IR Receiver: | x1 |
Tension d'alimentation: | 100-120V/30A~ 50/60Hz or 220-240V/15A~ 50Hz (vary by country) |
Consommation électrique: | 1500W (typ), 2500W (max) < 0.5W (Sleep), < 0W (Off) |
Température de fonctionnement: | 0~40℃ |
LED Module Quantity: | 100 |
Ingress Protection Rating: | IP30 |
Poids net: | 564 lbs (253 kg) |
Gross Weight: | 998 lbs (453 kg) |
Screen Dimensions (WxHxD): | 1800x1963x770 mm(min.) 3010x2613x770 mm(max.) |
Packing Dimensions (WxHxD): | 74.8x80x31.5 inches (1900x2032x800 mm) |
Cordon d'alimentation: | x1 |
LAN Cable (Cat 5A): | x1 (5m) |
Télécommande: | x1 |
Guide de démarrage rapide: | x1 |
Spare Parts: | LED PCB Unit x7 |
Maintenance Tool: | LD-MK-001 x1 |
Maintenance Tool: | LD-MK-001 |
ViewBoard Cast Button(USB-C): | VB-WPS-001 |
ViewBoard Cast Button(USB-A+HDMI): | VB-WPS-003 |
