IFP6550-0

HDMI: x 1 (for all sources)
Audio (Earphone out): x 1
SPDIF: x 1

RJ45: x 1

2.0 Type A: x 4 (front x 2, for both embedded player and slot-in PC)
3.0 Type A: x 2 (front x 1, for both embedded player and slot-in PC)
2.0 Type B (For touch): x 2

16W x 2

Processor: ARM Cortex A53 Quad Core 1.2G Hz CPU
Graphic: ARM Mali-450 Quad Core
Memory: 2GB DDR3
Storage: 16GB eMMC
Networking: 10/100M auto-identification and DHCP

VGA: Refer to timing table
HDMI: 3840x2160
DP: 3840x2160
CVBS: 480i

Voltage: 100-240VAC +/- 10% Wide Range
Consumption: 190W(Typ, without Slot-In PC); 285W(Typ, Including Slot-In PC)

Wall Mount (VESA® ): 600 x 400mm; Screw: M8 x 25mm

Temperature (º C): 32°F to 104°F (0°C to 40°C)
Humidity: 10% ~ 90% non-condensing

Physical w/o Stand (mm / inch): 1521 x 922 x 99 / 59.9 x 36.3 x 3.9
Packaging (mm / inch): 1697 x 1071 x 220 / 66.81 x 42.17 x 8.66

Net (kg / lb): 47kg / 103.62lbs
Gross (kg / lb): 60kg / 132.28lbs

VGA cable(5 meters)/Power cable(3 meters) x 4/Remote control/USB cable(5 meters)/Audio cable(5 meters)/AV cable/Touching pen x 3/User manual CD wizard/Quick Start Guide/RS232 adapter/Clamp x 5/Plate/Screw x 3
